Male Jumper Pins | Precision Cold-Formed | Manufacturer

Male header pins are used to interface PCBs with other boards, cables, or connector housings. They provide reliable through-hole or press-fit electrical connections in applications spanning automotive ECUs, medical devices, computer hardware, and farm equipment control modules. The pin's geometry and retention feature determine how it anchors into the mating substrate or housing.

Electropin manufactures male jumper pins in lead-free brass and stainless steel, as well as other metals on request. Both materials are available without leaded brass, meaning all parts are fully REACH and RoHS compliant without requiring additional regulatory processing or substitution.

Electropin offers four retention feature options: Star, Tabs/Spline, Inscribed Square, and Flat. The star feature can expand the pin diameter by up to 50% greater than the original wire diameter, providing strong press-fit retention in metal or plastic substrates and effective anti-rotation performance in circuit board applications.

Electropin's male jumper pins support three primary mounting methods: through-hole PCB mounting, press-fit insertion into metal parts, and post-insertion into molded plastic housings. The appropriate retention feature is selected based on the substrate material and the required pull-out and anti-rotation strength for the application.

Electropin can begin manufacturing and deliver a first batch of cold-formed pins in as little as two weeks when raw materials are available. Production is highly scalable, so order volumes can be increased significantly as project needs evolve. Batches are delivered on a timeline agreed upon with the customer.

Yes. Electropin provides Design for Manufacturing (DFM) consultation, custom pin design refinement, and collaborative engineering support. With over 35 years of experience, owner Keith Brenton and his team work directly with customers to optimize pin geometry, material selection, and retention features for their specific manufacturing environment and performance requirements.
