PCB Pin Terminals | Zero-Scrap Cold-Form Manufacturing

Electropin's cold-form process achieves a defect rate of just 1 pin per 600,000,000 produced. Because the automatic die rolling process never dulls its tooling, dimensional consistency is maintained across the entire production run. This level of accuracy significantly outperforms machined pin alternatives, reducing assembly rejects and warranty exposure.

Yes. All Electropin PCB pin terminals are available in lead-free brass and stainless steel, which eliminates the regulatory thresholds that apply to leaded brass used in conventional machined pins. This means your supply chain is fully REACH and RoHS compliant without requiring additional testing, documentation, or material substitution processes.

Electropin manufactures PCB pin terminals in lead-free brass and stainless steel. Lead-free brass provides excellent electrical conductivity and is the most common choice for connector applications. Stainless steel is selected where higher mechanical strength or corrosion resistance is required. Custom material options may also be discussed during the DFM consultation process.

Electropin offers four primary retention features: Star, Tabs/Spline, Inscribed Square, and Flat. The Star feature can expand pin diameter by up to 50% over the base wire diameter, providing high pull-out resistance. Tabs and Spline features deliver anti-rotation performance. The right retention geometry depends on whether the pin is press-fit into metal, inserted into plastic, or mounted through a PCB.

Electropin's PCB pin terminals support three primary mounting methods: through-hole PCB mounting, press-fit into metal, and post-insertion into molded plastic parts. Each mounting method can be combined with the appropriate retention feature — Star, Spline, Inscribed Square, or Flat — to meet specific pull-out force and anti-rotation requirements for your application.

When raw materials are available, Electropin can begin manufacturing and deliver your first batch in as little as two weeks. Subsequent batches are delivered on a timeline that works for your production schedule. Production volume can also be scaled dramatically to accommodate changes in demand without sacrificing lead time or quality.
