Industrial-Grade PCB Lead Pins | Wholesale

Electropin's PCB lead pins are available in lead-free brass and stainless steel. Lead-free brass offers good conductivity and formability, while stainless steel provides enhanced strength and corrosion resistance. Both options are fully REACH and RoHS compliant, making them suitable for automotive, medical, and electronics applications.

Electropin uses Automatic Die Rolling, a cold-forming process that shapes pins by rolling wire through precision dies rather than cutting. This produces zero in-process scrap, eliminates tool dulling, and enables production rates of up to 5 pins per second — resulting in consistent quality across runs of millions of parts.

Electropin's automatic die rolling tools never dull, ensuring every pin meets exact specifications without variation. This results in an exceptionally low defect rate of just 1 in 600,000,000 pins, delivering consistent, high-precision quality from the first pin to the millionth.

Electropin offers four retention feature types: Star, Tabs/Spline, Inscribed Square, and Flat. The star feature can expand pin diameter up to 50% greater than the base wire diameter, providing strong press-fit or post-insertion holding force and reliable anti-rotation performance in both plastic and metal substrates.

Electropin's PCB lead pins serve the automotive, medical devices, computer and electronics, and farm equipment industries. Applications range from automotive connectors requiring high retention strength to medical device PCB assemblies where precision, compliance, and zero-defect output are critical, as well as agricultural machinery wiring harnesses and high-speed electronics manufacturing.

Electropin's pins support three primary mounting methods: through-hole PCB mounting for circuit board assembly, press-fit into metal parts, and post-insertion into molded plastic components. Certain pin types — such as grooved and hinge pins — are also compatible with high-speed automated assembly track systems.

Electropin can begin manufacturing and deliver a first batch of custom connector pins in as little as two weeks, subject to raw material availability. Subsequent batches are delivered on a customer-specified schedule, and production volume can be scaled rapidly to meet changing demand without retooling delays.
